Interfacing with SerenityOS from Python

As my first post related to SerenityOS development, I’m going to talk about a topic which I’m really passionate about – Python programming!

SerenityOS has a pretty decent port of the Python language, mainly due to the work done by Linus (and other contributors!). Almost every standard library module works as intended, with many of its optional dependencies also ported, like sqlite, zlib, ncurses. Fun fact: webbrowser module has official support for launching the Serenity’s Ladybird Browser.

One of such optional dependencies is libffi, which is a foreign-function interface library. Having this dependency makes the ctypes module available.

With ctypes, we can easily call C compatible functions exported by a shared library, which means it should be possible to interface with the Serenity C++ classes, providing that we write wrapper functions in the style of C, and use the extern "C" declaration.

Let’s build a small “hello world” C-reni-Py (😅) program!

Creating a shared library

To create a shared library the easiest way possible, I’m going to use the same structure as the other libraries, by creating a new directory in the Userland/Libraries. Let’s call it LibExample:

1
2
3

cd serenity
mkdir -p Userland/Libraries/LibExample && cd $_
touch CMakeLists.txt Example.cpp Example.h

We’re going to build a really simple one-function library that sends (push-like) desktop notifications!

1
2
3
4
5
6

/* Example.h */
#pragma once

extern "C" {
    int notify(char const* title, char const* text);
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

/* Example.cpp */
#include "Example.h"
#include <LibGUI/Notification.h>

int notify(char const* title, char const* text)
{
    auto notification = GUI::Notification::construct();
    notification->set_title(title);
    notification->set_text(text);
    notification->show();
    return 0;
}

Nice! Now, to make the build system compile this code, it’s necessary to edit CMakeLists.txt:

1
2
3
4

serenity_component(LibExample TARGETS LibExample)
set(SOURCES Example.cpp)
serenity_lib(LibExample example)
target_link_libraries(LibExample PRIVATE LibCore LibGUI LibGfx)

I’m not sure if this declaration is entirely correct (as I don’t fully understand the build system), but I found that serenity_component() must be present. Otherwise, the library won’t be placed in the OS filesystem (I assume it’s because it’s not a dependency of any application).

Now, edit Userland/Libraries/CMakeLists.txt and add an add_subdirectory(LibExample) declaration. Build the system and run it. Check that there is a /usr/lib/libexample.so file!

Using the library from Python

Assuming that you already have the Python port installed, let’s use the library. Open a Python interpreter and type:

1
2
3

from ctypes import CDLL
lib = CDLL("libexample.so")
lib.notify(b"Well", b"Hello friends")

And…

It crashed! (At least the error is pretty cool)

Apparently, before we can create notifications, we need to have an event loop instantiated, which in Serenity it’s done by initializing a GUI::Application object. I’m not entirely sure why, I think it’s related to the way GUI applications communicate with WindowServer.

After declaring a global variable static RefPtr<GUI::Application> app, I’m going to initialize it in the first invocation of notify(). Something like this:

1
2
3

if (!app) {
    app = GUI::Application::construct(Main::Arguments {});
}

And there we go! Displaying a notification on the SerenityOS desktop, via Python:

(I also introduced an icon file as a third parameter, so I could find a reason to show the wholesome catdog mascot in this post.)

With this approach, it’s theoretically possible to build Python bindings for LibGUI (and other components), but it’s really hard work to do that, I think. Another way to build this kind of integration is to use the CPython C API.

That’s all for today. I hope you find this post interesting in any way. x)
